Description
-Centrifugal Die Cast Aluminum Trim Pre-Treated
Before Powder Coating For Corrosion Resistance
-Cold Forged Aluminum Heatsink
-Optical Grade PC with UV Coated Reflector
-Prismatic Diffuser For Low UGR
-High Lumen & High CRI COB LEDs used
-Mounting: Snap-in cutout in false ceiling
DRDR-W
Technical Details
| Light Source | COB |
| Input Power | 12W / 15W / 18W
|
| Input Voltage | 220-240VAC
|
| Beam Angle | 56°
|
| Color Temperature | 2700K/ 3000K/ 4000K/ 5000K/ 6000K/ 2700K-5000K RF + Dual Color |
CRI
| 90
|
|---|
| Driving System | Constant Current/ TRIAC Dimming / R.F Dimming/ R.F. + DUAL COLOR/ DALI Dimming |
|---|
| Color Tolerance | max 3 sdcm
|
| Operating Temperature | -10 to 50°C
|
|---|
System Warranty
| 1 Year
|
| Model | Color | Watt | Beam Angle | Color Temp | Lumen |
DRD
| White - R
| 12 Watt
| Wide - 56°
| 2700K | 954 lm
|
DRD
| White - R
| 12 Watt
| Wide - 56°
| 3000K | 1003 lm
|
DRD
| White - R
| 12 Watt
| Wide - 56°
| 4000K | 1053 lm
|
DRD
| White - R
| 12 Watt
| Wide - 56°
| 5000K | 1093 lm
|
DRD
| White - R
| 12 Watt
| Wide - 56°
| 6000K | 1040 lm
|
DRD
| White - R
| 15 Watt
| Wide - 56°
| 2700K | 1114 lm
|
DRD
| White - R
| 15 Watt
| Wide - 56°
| 3000K
| 1161 lm
|
DRD
| White - R
| 15 Watt
| Wide - 56°
| 4000K
| 1172 lm
|
DRD
| White - R
| 15 Watt
| Wide - 56°
| 5000K
| 1230 lm
|
DRD
| White - R
| 15 Watt
| Wide - 56°
| 6000K
| 1277 lm
|
DRD
| White - R
| 18 Watt
| Wide - 56°
| 2700K | 1458 lm
|
DRD
| White - R
| 18 Watt
| Wide - 56°
| 3000K | 1519 lm
|
DRD
| White - R
| 18 Watt
| Wide - 56°
| 4000K | 1534 lm
|
DRD
| White - R
| 18 Watt
| Wide - 56°
| 5000K | 1610 lm
|
DRD
| White - R
| 18 Watt
| Wide - 56°
| 6000K | 1671 lm
|
Downloads
PDF - DRDR- W - 12W-15W-18W
IES - DRDR-12W DRDR-15W DRDR-18W
